Tactacam - Reveal X 4.0 Cellular Trail Camera
Model: RV-TC-XP4
Choose Your Bundle Items
Tactacam - Reveal X 4.0 Cellular Trail Camera
Tactacam - Reveal Solar Panel R5 with Built-In Battery
Extend the time between trail-camera visits with the Tactacam REVEAL Solar Panel R5 with Built-In Battery. Designed for REVEAL cellular trail cameras, the R5 combines a larger solar surface, a built-in 5,000 mAh lithium-ion battery, and an adjustable mounting bracket to deliver more efficient off-grid power for long-term scouting setups.
The Solar Panel R5 charges up to 30% faster than the previous Solar Panel V2 and reaches 21% solar conversion efficiency. When connected by barrel jack to a REVEAL X 4.0 or REVEAL Pro 4.0, it unlocks Advanced Insights for battery percentage, charging state, voltage readings, diagnostics, and other power-monitoring information. Shop more Tactacam products or browse our Trail Cameras collection.
FASTER, MORE EFFICIENT SOLAR CHARGING
The R5 uses a larger solar surface and improved charging system to capture more energy in the field. Tactacam rates the R5 at 30% faster charging than the Solar Panel V2, helping reduce downtime and maintenance visits.
BUILT-IN 5,000 MAH BACKUP BATTERY
An integrated 5,000 mAh lithium-ion battery stores power for nighttime operation and cloudy conditions, giving compatible trail cameras an additional energy reserve when direct sunlight is unavailable.
ADVANCED INSIGHTS WITH REVEAL 4.0 CAMERAS
When connected to a REVEAL X 4.0 or Pro 4.0 through the DC barrel connection, the Solar Panel R5 can provide Advanced Insights such as battery percentage, charging state, voltage readings, diagnostics, and panel-performance information. This makes it easier to fine-tune solar-panel placement and monitor power-system health remotely.
WIDE REVEAL CAMERA COMPATIBILITY
The Solar Panel R5 is compatible with REVEAL cameras that use a barrel-jack power connection, including the Pro 4.0, X 4.0, Pro 3.0, X 3.0, Ultra, X-Pro, X Gen 2.0, XB/SK, X, and Gen 1 models. Advanced Insights are limited to compatible REVEAL 4.0 cameras connected through the barrel jack.
FEATURES
- Built-in 5,000 mAh lithium-ion battery
- 30% faster charging than the REVEAL Solar Panel V2
- 21% solar conversion efficiency
- Advanced Insights with REVEAL X 4.0 and Pro 4.0 via barrel-jack connection
- Battery percentage, charging state, voltage, diagnostics, and other power-monitoring data with compatible 4.0 cameras
- Adjustable mounting bracket for panel-angle positioning
- Compatible with REVEAL cameras using a barrel-jack power connection
- DC barrel output for trail-camera power
- USB-C charging input
- Designed for reduced trail-camera maintenance and fewer battery-change visits
SPECIFICATIONS
- Model: REVEAL Solar Panel R5
- SKU: RV-EXT-V3
- Built-In Battery: 5,000 mAh at 7.2V lithium-ion
- USB-C Input: 5V / 3A
- DC Barrel Output: 12V / 2A for Gen 2; 7.4V / 3A for Gen 3, Pro 3.0, Defend Cam, X 4.0 and Pro 4.0
- Solar Conversion Efficiency: 21%
- Solar Panel: 12.24V, 4.2W
- Charging Time: 50–120 hours using solar power; approximately 3.5 hours using AC adapter
- Dimensions: 32.5 mm D x 149 mm W x 203 mm H
- Weight: 1 lb. 11 oz.
- Output Plug: DC barrel
- Mounting: Adjustable bracket
- Operating Temperature: -4°F to 140°F (-20°C to 60°C)
- Operating Humidity: 5%–95%
WHAT'S INCLUDED
- REVEAL Solar Panel R5 with mount
- 1 strap
- 1 USB-C charging cable
- 1 barrel-jack cable with retention clip
TACTACAM REVEAL SOLAR PANEL R5 FAQ
Which Tactacam cameras work with the REVEAL Solar Panel R5?
The Solar Panel R5 works with REVEAL cameras that use a barrel-jack power connection, including the Pro 4.0, X 4.0, Pro 3.0, X 3.0, Ultra, X-Pro, X Gen 2.0, XB/SK, X, and Gen 1 cameras.
What are Advanced Insights on the Solar Panel R5?
When the Solar Panel R5 is connected by barrel jack to a REVEAL X 4.0 or Pro 4.0, Advanced Insights can provide information such as battery percentage, charging state, voltage readings, diagnostics, and other panel-performance data.
Does the Solar Panel R5 have a built-in battery?
Yes. It includes a built-in 5,000 mAh lithium-ion battery that stores power for nighttime use and cloudy conditions.
How much sunlight does the REVEAL Solar Panel R5 need?
Tactacam recommends placing the panel where it can receive at least four hours of sunlight per day for optimal performance.
Will the Solar Panel R5 charge AA batteries inside my trail camera?
No. The Solar Panel R5 does not charge standard AA batteries. Tactacam states that it can charge compatible FlexPack R5 or R10 modular batteries.
How fast does the Solar Panel R5 charge?
Tactacam rates the R5 at 30% faster charging than the previous Solar Panel V2. Charging time is approximately 50–120 hours using solar power or about 3.5 hours using an AC adapter.
Tactacam - Reveal Flexpack™ R5 Power System Rechargeable Battery
Power your REVEAL 4.0 cellular trail camera with the Tactacam REVEAL FlexPack™ R5 Power System Rechargeable Battery. Designed exclusively for the REVEAL 4.0 platform, the compact R5 uses a 5,000 mAh lithium-ion battery to deliver longer field runtime while reducing the need for disposable AA batteries.
The FlexPack R5 installs directly into compatible REVEAL 4.0 cameras for a clean, integrated power solution and can replace up to 1,000 AA batteries over its service life. Recharge it with the included USB-C cable or pair it with the REVEAL Solar Panel R5 for a more maintenance-friendly field setup. It is compatible with the REVEAL X 4.0, REVEAL Pro 4.0, and REVEAL Pro 4.0 Solar.
5,000 MAH RECHARGEABLE POWER
The FlexPack R5 uses a 5,000 mAh, 7.2V lithium-ion battery built around two 21700 cells. Its rechargeable design helps extend camera runtime and reduces repeated trips to swap disposable batteries.
DESIGNED FOR REVEAL 4.0 CAMERAS
The R5 is engineered specifically for the REVEAL 4.0 camera platform. Its modular shape installs directly into compatible cameras with minimal added bulk and can be quickly removed when it is time to recharge or swap power systems.
LOWER BATTERY COST AND WASTE
Tactacam states that one FlexPack R5 can replace up to 1,000 disposable AA batteries, making it a practical option for hunters and land managers running multiple cellular trail cameras over long periods.
FAST USB-C CHARGING
Using a 5V/3A power source, the FlexPack R5 charges in approximately 3.5 hours. The included USB-C cable makes it easy to recharge between deployments.
FEATURES
- 5,000 mAh rechargeable lithium-ion battery
- 7.2V battery system using two 21700 cells
- Designed specifically for REVEAL 4.0 cameras
- Replaces up to 1,000 disposable AA batteries
- Quick-swap modular design
- Compact fit with minimal added bulk
- Durable, weather-resistant construction
- Approximately 3.5-hour charge time with 5V/3A power source
- Includes USB-C charging cable
- Compatible with REVEAL Solar Panel R5
SPECIFICATIONS
- Model: REVEAL FlexPack™ R5 Power System
- SKU: RV-TC-4LC-5
- Battery Capacity: 5,000 mAh
- Battery Voltage: 7.2V
- Battery Type: Lithium-ion, 2 x 21700 cells
- Dimensions: 94 x 52 x 71 mm
- Weight: 9 oz.
- Output Plug: DC barrel jack
- Operating Temperature: -4°F to 140°F (-20°C to 60°C)
- Operating Humidity: 5%–95%
- Charging Time: Approximately 3.5 hours with 5V/3A source
COMPATIBLE WITH
- REVEAL Pro 4.0
- REVEAL X 4.0
- REVEAL Pro 4.0 Solar
WHAT'S INCLUDED
- REVEAL FlexPack R5 rechargeable battery
- USB-C charging cable
TACTACAM REVEAL FLEXPACK R5 FAQ
Which Tactacam cameras work with the FlexPack R5?
The FlexPack R5 is designed for the REVEAL 4.0 platform and is compatible with the REVEAL Pro 4.0, REVEAL X 4.0, and REVEAL Pro 4.0 Solar.
Does the FlexPack R5 work with REVEAL 3.0 cameras?
No. Tactacam specifies that the FlexPack R5 is for REVEAL 4.0 cameras and is not compatible with REVEAL 3.0 models.
How many AA batteries can the FlexPack R5 replace?
Tactacam states that the R5 can replace up to 1,000 disposable AA batteries over its service life.
How long does the FlexPack R5 take to charge?
When using a 5V/3A power source, charging takes approximately 3.5 hours.
Can the FlexPack R5 be used with a solar panel?
Yes. The R5 can be paired with the Tactacam REVEAL Solar Panel R5 for a longer-running, lower-maintenance trail camera power setup.
What is included with the FlexPack R5?
The package includes one FlexPack R5 rechargeable battery and one USB-C charging cable.
Description
Scout smarter with the Tactacam REVEAL X 4.0 Cellular Trail Camera, a dependable everyday cellular trail camera built for hunters who want strong battery life, reliable connectivity, and improved image and video quality without unnecessary complexity. The X 4.0 captures 4K photos and 1080p video, features built-in GPS, Low-Glow IR illumination, and automatically connects to the strongest available cellular network.
The REVEAL X 4.0 adds Live View Mode and on-demand video access with an eligible subscription, simultaneous photo and video capture, 8GB of internal storage with an optional SD card slot, and compatibility with Tactacam’s REVEAL FlexPack™ Power System. Run it on 12 AA batteries or upgrade to an optional FlexPack R5 or R10 rechargeable power system for longer deployment between field visits. Shop more Tactacam products or browse our full Trail Cameras collection.
FEATURES
- Industry-leading battery life for extended field deployment
- 4K photo resolution and 1080p video
- Improved daytime image and video quality
- Live View Mode*
- On-demand video*
- Simultaneous photo and video capture with zero delay between triggers
- Built-in GPS tracking
- Auto-carrier selection connects to the strongest available cellular network
- Low-Glow IR flash with up to 96-foot range
- REVEAL FlexPack™ Power System compatibility
- Runs on 12 AA batteries or optional FlexPack R5 5,000 mAh / R10 10,000 mAh rechargeable power systems
- 8GB internal storage with optional SD card slot
- Rugged field-ready design
- Integrated SIM card
SPECIFICATIONS
| Warranty | 1 year from activation date |
|---|---|
| Cellular Network | LTE |
| Cellular Carrier | Major Cellular Networks with Auto-Carrier Selection |
| Photo Definition | 4K (UHD), 2.5K (WQHD) |
| Video Resolution | 1080p Full HD |
| Flash Range | Low-Glow IR: 96 ft. |
| Memory | 8GB Internal Storage with Optional SD Card Slot |
| Power | 12 AA batteries (not included); compatible with optional FlexPack R5 and R10 power systems |
| External Power | DC 12V-2A Input |
| Included | Camera, antenna, tree strap, integrated SIM card, AA battery pack |
*Live View Mode and on-demand video require an additional subscription.
TACTACAM REVEAL X 4.0 FAQ
Does the Tactacam REVEAL X 4.0 require a cellular plan?
Yes. Cellular image and video transmission requires an active Tactacam REVEAL cellular plan. Some advanced features, including Live View Mode and on-demand video, require an additional eligible subscription.
Which cellular carrier does the REVEAL X 4.0 use?
The REVEAL X 4.0 uses auto-carrier selection to connect to the strongest available supported cellular network in the camera’s location.
Does the REVEAL X 4.0 have Live View?
Yes. Live View Mode is available with the required subscription, allowing you to view the camera remotely through the Tactacam REVEAL system when network conditions support the feature.
What batteries does the Tactacam REVEAL X 4.0 use?
The camera runs on 12 AA batteries and is also compatible with optional Tactacam FlexPack R5 and R10 rechargeable power systems for longer field deployment.
Does the REVEAL X 4.0 require an SD card?
No. The camera includes 8GB of internal storage, and an optional SD card slot is available for additional storage.
What is the difference between the REVEAL X 4.0 and REVEAL Pro 4.0?
The X 4.0 is a streamlined cellular trail camera with Low-Glow IR, while the REVEAL Pro 4.0 adds premium features including dual image sensors, selectable No-Glow or Low-Glow IR, enhanced low-light performance, and a side-facing LCD screen.
